Entity Tag

The EntityTag class provides an identifier for atomic nuclei and particles. Nautilus provides a number of translators to bidirectionally convert between EntityTag and other formats commonly in use. The primary advantage that EntityTag provides beyond what can be found in other formats is a versioning code attached to the identifier, allowing the EntityTag format to evolve to correct mistakes and to expand or change the features available. Most identifiers that have been in use for an extended period of time suffer from a number of “quirks” that have accumulated over time for various reasons and cannot be completely eliminated due to the need to preserve consistency and compatibility.

XKCD comic number 927, "Standards"

XKCD comic number 927, https://xkcd.com/927, Creative Commons Attribution-NonCommerical 2.5 License

The objective for Nautilus’s EntityTag is not to provide a new “super-format” that supports every possible use-case and replaces all similar formats in all codes. The primary value of EntityTag will be in its ability to translate between multiple formats in a consistent way, and to parse existing formats in a way that automatically corrects for all of their historical quirks. If customers are interested in using EntityTag as their new internal representation, the Nautilus team will be pleased to continue supporting them.

Core Features

An EntityTag can encode three different kinds of entities:

  • an unknown entity

  • a standard entity

  • a user-defined entity

Standard entities further break down into three categories:

  • particles

  • elementals

  • nuclides

All instances of EntityTag have the following accessors:

  • current_version() is a static function that returns the most-recent version of EntityTag available (currently 0)

  • get_version() returns the version of this instance of EntityTag

  • is_unknown() returns true for unknown entities and false otherwise

  • is_standard() returns true for standard entities and false otherwise

  • is_user() returns true for user-defined entities and false otherwise

All instances of EntityTag also have a family of set() methods with the same arguments and behavior as the various constructors discussed below.

Comparison operators are also available: ==, !=, <=, >=, <, and >. The ordering implied by the inequality operators is

  • particles (ordering between particles unspecified, but will be consistent for a given version of EntityTag)

  • elementals

  • nuclides, sorted by atomic number (most-significant), then atomic mass number, then metastable state index (least-significant)

  • user-defined entities (ordering depends on user data)

  • unknown entities last

Unknown Entities

An “unknown” entity indicates that the EntityTag was not initialized or that the translation routine was unable to correctly map from another format into the EntityTag format.

To build an unknown entity, either call the default constructor (EntityTag()) or the explicit “unknown” constructor (EntityTag(EntityTag::unknown)).

Standard Entities

Standard entities include particles, elementals, and nuclides. To differentiate, the following accessors are available:

  • is_particle() will return true for particles; false for elementals, nuclides, and non-standard instances

  • is_elemental() will return true for elementals; false for particles, nuclides, and non-standard instances

  • is_nuclide() will return true for nuclides; false for particles, elementals, and non-standard instances

Particle Entities

The only additional accessor available for particles is get_particle_index(), which will assert that the entity is a particle and then return an index for the particle. The particle index is not intended to encode a specific meaning. Instead, Nautilus defines a number of compile-time constants in nautilus/entity_tag/names.hpp for the various particles known to Nautilus. For example, to see if a particle is a muon would be entity.get_particle_index() == names::muon. Be aware that the specific values for these compile-time constants are not meaningful and could change.

To construct a particle tag use the constructor EntityTag(particle_index), where the particle index should be one of the compile-time constants from nautilus/entity_tag/names.hpp.

Elemental Entities

Elementals only have a single property: the atomic number. This can be queried by either get_atomic_number() or get_Z(). To construct an elemental tag, use the constructor EntityTag(atomic_number).

Nuclide Entities

In order to query the properties of nuclei, the following accessors are available. All of them assert that the accessor is a valid query, providing a sanity check when building Nautilus in debug mode. For example, get_atomic_number() is valid for both nuclides and elementals, while get_atomic_mass_number() is only valid for nuclides.

  • get_atomic_number() and get_Z() return the atomic number

  • get_atomic_mass_number() and get_A() return the atomic mass number

  • get_neutron_number() and get_N() return the neutron number

  • get_metastable_state() returns the index of the excited state, with zero being the ground state

  • is_ground() indicates if the entity is in the ground state (true) or an excited state (false)

A few notes regarding the metastable / excited state:

  • The metastable state index does not have a recognized shorthand like \(Z\), \(N\), or \(A\). For example, NDI formats use the symbol \(S\) while MCNP formats use the symbol \(m\). For this reason, no shorthand accessor is provided in Nautilus.

  • Because the metastable state is not well-defined, Nautilus cannot convert between different definitions of “metastable” or between metastable and excited state indices. If the user sets a metastable state index, Nautilus will simply report back that same index, assuming that the user is ensuring that the definition of “metastable” is consistent between the formats. If the user wants to use an excited state index it is up to the user to recall that they have defined the list of metastable states to be “all excited states”.

To construct a nuclide tag, use the constructor EntityTag(atomic_number, atomic_mass_number, metastable_index). The metastable index can be left off, in which case it will default to the ground state (metastable index of zero).

User-Defined Entities

A user-defined entity is simply space for users to add their own custom entities, defined according to their own needs. Examples of this could be

  • Some astrophysics codes define simplified thermonuclear reaction networks with “pseudo-materials” that are some useful distribution of elements and isotopes that provide a “good enough” approximation intermediate to a calculation.

  • Some transport codes may need particles that Nautilus has not yet defined, including known particles that didn’t make the list or theoretical particles that have not yet been observed experimentally.

  • The user may wish to duplicate one of the standard formats but also pack some “extra” information into a Nautilus EntityTag for bookkeeping purposes (such as “this is a proton, and we use the data from such-and-such source”).

The only accessor for user-defined entities is get_user_data(), which returns the data that the user chose to encode into the EntityTag.

To construct a user-defined entity use the constructor EntityTag(EntityTag::user, user_data), which builds a user-defined entity with the specified user data. EntityTag encodes user data into 25 bits. The value where all 25 bits are set to one is a special value that is reserved for Nautilus, so users should not attempt to set that value. Invalid values will generate an error (if debugging is turned on) or silently do the wrong thing (if assertions are compiled out).
